Overview

AZE's Air‑Conditioned Outdoor Field Cabinets provide a complete, high-integrity housing solution for sensitive electrical and data network equipment operating in harsh outdoor environments. By combining a rugged, IP55-rated enclosure with a purpose-built air conditioning system, these cabinets deliver precise thermal management and robust physical protection in a single, integrated unit.

Designed for demanding applications such as road traffic management, Intelligent Transport Systems (ITS), telecommunications, and industrial infrastructure, these cabinets ensure operational continuity by safeguarding equipment from extreme temperatures, dust, water spray, vandalism, and corrosion.

Integrated Active Cooling
Each cabinet features a thermally isolated compartment housing an air conditioner, ranging from 300 W to 5 kW. This dedicated cooling system maintains optimal internal temperatures while the main 19" rack compartment remains fully sealed against external contaminants.

Rugged, Corrosion-Resistant Construction

• Material Options: Choose from 1.5 mm galvanised steel or marine-grade aluminium for superior longevity in coastal or industrial environments.

• Protective Finish: Durable powder coating provides long-lasting corrosion resistance.

• Environmental Rating: IP55 protection ensures reliable performance against dust ingress and water spray.

Designed for Public Spaces & Security

• Vandal-Resistant Design: Recessed doors and secure locking mechanisms deter tampering and unauthorised access.

• Thermally Managed Airflow: The air conditioner is accessed via a dedicated side door with a louvred vent hood, optimising airflow and heat dissipation while maintaining security.

Smart, Maintenance-Friendly Features

• Reliable Sealing: Full perimeter foam-in-place (FIP) polyurethane seals prevent leakage and ensure long-term integrity.

• Easy Cable Management: Integrated split gland plates simplify cable entry and termination.

• Monitoring & Control: Thermostatic control and alarm outputs come as standard, with optional remote monitoring via RS485 interface.

Why Choose AZE's Air-Conditioned Outdoor Field Cabinets?

• Complete Integrated Solution: One cabinet, one supplier—combining high-performance cooling with rugged mechanical protection.

• Proven Compliance: Certified to international and Australian/New Zealand standards, providing confidence for regulatory and tender requirements.

• Designed for Long Life: Heavy-gauge materials, premium powder coating, and high-quality FIP seals ensure decades of reliable service.

• Field-Proven: Engineered specifically for the demands of road traffic management, ITS, and outdoor industrial applications.

• Security Built-In: Recessed doors and 3-point locking provide robust protection against tampering in public environments.

Protect your critical assets in even the harshest conditions. Choose AZE's for mission-critical outdoor installations.

Specification

How to Order

**********Notes**********

• Shipping Option: Assembly unit with carton or wood pallet
• Waterproof outdoor electrical enclosures IP Rating: IP55,IP65 rated or NEMA 3R,NEMA 4, NEMA 4X rated available
• Outdoor Enclosures Material Options: SPCC Cold Steel, Galvanized steel, Stainless steel or Aluminum available.
• Outdoor Telecom Cabinet Cooling options:  such as cooling fans, Cabinet air conditioner , Plate heat exchanger and Thermoelectric cooler available.

• A wide range of server rack accessories ,Fiber optics cabling solutions,Server Rack PDUs and KVM solutions compatablity
• Grey(RAL7035) or other customize colors available
• Outdoor telecom enclosure optional accessory parts

Outdoor enclosures can be customized for all Outside Plant applications - special engineering and additional equipment integration also available. Additional cabinet sizes are available. Call us or email us for information and pricing.
